SparkFun Lightning Detector - AS3935 Add Lightning detection to your weather station Programmable detection level Distance to storm estimator Indoor-Outdoor setting SPI Interface 3.3V logic Small size

Brand: SparkFun

Color: Red

Features:

• Detect lightning with ease. Solder headers on to connect to your microcontoller and go. (Arduino-Compatible)
• Detects strikes from up to 40km away with accuracy of 1km in 14 steps. Enjoy studying the weather.
• Includes a ?œDisturber??(false event) rejection algorithm. Avoid false positives and noise in your project.
• Features a sensitive antenna tuned to pick up lightning events in the 500kHz band.
• Supply Voltage: 2.4V-5.5V. Recommended 3.3V. 3.3V logic, be sure to use a logic level converter where needed.

model number: 15441

Part Number: 15441

Details: The SparkFun Lightning Detector adds lightning detection to your next weather station to make sure you are aware of any potential hazardous weather heading your way. The AS3935 is capable of detecting lightning up to 40km away with an accuracy of 1km to the storm front with a sensitive antenna tuned to pick up lightning events in the 500kHz band.
There are a number of sources that can cause false positives but the lightning detector itself can reliably filter these out by default. If not, we've made sure to include settings you can configure using the lightning detector library to increase the chip's robustness to noise and false positives. The lightning detector library also gives you access to settings such as storm sensing sensitivity when detecting indoors vs outdoors, or the number of lightning strikes needed to trigger an interrupt.
Lightning Sensing
40km Range with accuracy of 1km in 14 steps
Features
Programmable Detection Levels
Distance to storm estimation
"Disturber" (false event) rejection algorithm
Indoor and Outdoor Settings
SPI Interface
Operating Range
Supply Voltage: 2.4V - 5.5V

EAN: 0845156009756

Package Dimensions: 3.4 x 3.1 x 0.1 inches
